2011 سنوركيل A38E

Maximum lift capacity: 215.00
Transport dimensions (LxWxH): 4.1x1.5x2
Front tyres remaining: 70
Rear tyres remaining : 70
Internal stock no.: SNORKEL - A38E - 63598
Gross Weight: 3770.00
Tyre brand: -
VAT: 0.00
Working height: 1350.00
Max horizontal reach: 610.00
Other information: Manufacturer: Snorkel Typ: A38E Building year: 2011 Fuel: Electric Serial number: A38E-01-004589 Max. working height: 13.5m Max. platform height: 11.5m Max. horizontal reach: 6.1m Clearance height at max. outreach: 5.4m Platform floor size (inside) 0.69m x 1.11m Overall length: 4.1m Overall width: 1.5m Stowed height: 2.0m Ground clearance: 120mm Platform capacity (SWL) 215kg Max. drive height 11.5m Max. drive speed (elevated) 0.65km/h Max. drive speed (stowed) 4.0 km/h Gradeability: 36% Superstructure rotation: 360° non continuous Tailswing (riser boom elevated) 0m Tailswing (riser boom stowed) 1.4m Inside turning radius 1.12m Outside turning radius 2.4m CE (Declaration of Conformity). More detailed pictures / product movie on our website. pfeifermachinery.com Above specifications are subject to change without prior notice and subject to errors
