95hp Dongfeng brand mini truck specification

Truck Model ： JSIE5201
Driving model ： 4x2
1. Base specification
Overall dimension (mm): 4980 x 2050 x 2250
Totally weight (kg): 4500
Curb weight (kg): 2800
Wheelbase(mm): 2800
Hang front/rear (mm): 950/1100
Tread front/rear (mm): 1740/1680
2. Chassis specification
Engine ： Quanchai brand 4B2-95C30
Engine model ： line ,water cooler ,turbo ，EURO 3
Rate power (km/rpm) 95hp /70kw
Engine displacement ： 2.545L
Fuel : diesel
Transmission : manually ,5 forward /1 reverse
Beam : 215/80/6mm
Front axle (kg): Dongfeng 1.8t axle
Rear axle (kg): Dongfeng 2.6t axle
Cab： Dongfeng
Steel spring : front 5pcs,rear 8pcs ,leaf spring
Brake system : running brake :dual circle air brake
parking system : air brake
Steering system : hydraulic assistant
Tires ： 6.50R16
A/C with
Windows type electric Windows
3. Cargo box
Box dimension (mm)： 3300x1750x500
Box sheet cover box insides walls covered by 1mm sheet metal
Dumping ： No
