2026 Boratas Washing Screens

Boratas BSTYE2060 Washing Screen is a stationary material washing and screening unit designed for rinsing and classification of aggregates in quarry, mining, and sand washing applications. It is used to remove clay, dust, and fine contaminants from end porudcts before downstream processing.

The Boratas sand washer machine is intended for installation in fixed wet processing plants where controlled washing intensity and reliable sorting performance are required. It is available in 3-deck or 4-deck models, allowing multiple material fractions to be cleaned and separated in a single unit.

Powered by a 22 kW electric motor, the machine delivers stable and continuous operation under heavy-duty conditions. Each deck is equipped with independently controlled washing pipes, enabling operators to regulate water flow per deck based on material type and contamination level. This provides flexibility and precise wash control across different applications.

Technical Specifications
• Screen Dimensions: 2000 x 6000 mm
• Motor Power: 22 kW
• Number of Decks: 3 or 4
• Weight (3 decks): approx. 8,500 kg
• Weight (4 decks): approx. 9,500 kg

Manufactured in compliance with global quality standards and supported by Boratas warranty after-sales service.

For further details about Boratas washing and screening machines, and other project-specific solutions, kindly visit our website www.boratasglobal.com. Feel free to contact us for your inquiries.

Standard Features:
2000 x 6000 mm screening surface.
3-deck or 4-deck configuration options.
22 kW electric drive motor.
Independent water flow control for each deck.
Full-surface rinsing system across all decks.
Heavy-duty structural design.

Optional Features:
Adjustable spray nozzles and water-saving systems.
Polyurethane, rubber, or wire mesh screen media.
Dust protection and water containment systems.
Automatic lubrication and sensor packages.
